22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch

22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
22MM 18A 250V 6Pin LED Light Button Switch Momentary Reset Metal Push Button Switch
$10.99
Ex Tax: $10.99
  • Stock: In Stock
  • Model: MZ008662
  • SKU: MZ008662

Available Options

Specification:
Rated insulated Voltage 250V
Insulated resistance ≥1000MΩ
Front protect class IP65
Withstand Voltage 1.5KV/60S
Work Frequency 50Hz
Stipulated hot current Ith 18A
Contact resistance ≤50mΩ
LED Light Color Blue, Green, White, Red, Yellow
Electrical life 50,0000 times
Mechanical life 200,0000 times
Terminal type (2.8*0.5mm) /(4.8*0.8mm)pin terminal
Size of mounding hole Φ22mm
Contact Silver Alloy
Pin Material Brass
Button Material Stainless steel
Body Material Brass

Package Included: 1 x Button Switch
