$214.99
Ex Tax: $214.99
  • Stock: In Stock
  • Model: MZ002537
  • SKU: MZ002537
Descriptions:

MDP (Mini Digital Power System) is a system of programmable linear DC power supply based on a modular design, capable of connecting different modules for use as needed.
Current Functional Modules: Display Control ModuleDigital Power Module
Modules in Develop: Digital Signal Genetator ModuleElectronic Load ModulePower Charger ModuleBattery Pack Module

MDP-XP consists of a display control module and a digital power module. Through a 2.4G wireless connection, it achieves multichannel-free combination at the power of 90W per channel. MDP-XP is a highly cost-effective programmable linear DC power supply, featuring indicators, stability, reliability, and a distinct user interface comparable with professional power supplies; it also provides programmable output, timing output, sequential control, automatic compensation, and other powerful functions, so as to meet diversified testing needs.

Display Control Module: equipped with a 2.8-inch TFT screen, it can display the voltage-current waveform in real time, support data statistics, and automatically pair with and control six sub-modules (digital power modules), with dual thumb wheels and 90-degree scrolling user-friendly design.
Digital Power Module: high-efficiency linear output, 0.25mV ripple wave, high-speed transient response, and supporting precise fine-tuning.

※Features:

- 2.4G wireless connection, supporting a Display Control as well as six Digital Powers
- DC wide voltage input between 4.2V and 30V, reduced up to 2.7V after startup
- High-speed transient response and over current protection, as fast as 4uS
- Extremely low load regulation and intelligent line loss compensation
- High efficiency and natural heat dissipation with 90W of capacity load
- Support positive & negative pressure, series pressurization, parallel current sharing, free combination of collaborative load, and intelligent power allocation
- Security Protections: input overvoltage, under-voltage protection, anti-reverse connection protection, anti-backflow protection, overtemperature protection, and over-current protection

※Applications:

General tests and teaching experiments in the R&D laboratory
Maintenance of cellphones, laptops, and other digital products
Power supply testing and data logger of RF and microwave circuits or modules
Supply purified power for high-accuracy digital-analog circuits and Hi-Fi audio devices
Property verification and fault diagnosis of devices and circuits
Quality control and quality inspection
Emergency power supply for model airplanes and vehicles

Specifications:

Mode MDP-XP
Input DC4.2V-30V(After startup 2.7V),100mA-6A,Support QC3.0
Output 30V/5A,90W
Adjustment rate Load adjustment rate <±0.01^%
Power adjustment rate <±0.01^%
Ripple and noise 250uVrms/3mVpp
Transient response time ≤4uS
Line loss compensation 5mR-100mR
Protection Input over-voltage,under-voltage, anti-reverse, output anti-backflow, over temperature
Data recording Max storage: 7MB, Max recording time: 24 hours.
Others Automatically shut down and enter micro-power mode
Support USB firmware upgrade
Support user calibration

Package Includes:

1 x MDP-XP Power System(1 x MDP-M01 Smart Digital Monitor + 1 x MDP-P905 Digital Power Supply)
1 x Cable (2.5mm audio head to Micro USB)
2 x Output Line (4mm banana head to crocodile clip)

Details Pictures:


MDP-XP-30V5A-90W-24G-Wireless-Connection-Digital-Programmable-Power-System-with-28-inch-TFT-Screen-M-1526966-1
MDP-XP-30V5A-90W-24G-Wireless-Connection-Digital-Programmable-Power-System-with-28-inch-TFT-Screen-M-1526966-2
MDP-XP-30V5A-90W-24G-Wireless-Connection-Digital-Programmable-Power-System-with-28-inch-TFT-Screen-M-1526966-3
MDP-XP-30V5A-90W-24G-Wireless-Connection-Digital-Programmable-Power-System-with-28-inch-TFT-Screen-M-1526966-4
MDP-XP-30V5A-90W-24G-Wireless-Connection-Digital-Programmable-Power-System-with-28-inch-TFT-Screen-M-1526966-5
