N20 DC12V 300RPM Mini Metal Gear Motor Electric Gear Motor Box

Description:
This is a DC Mini Metal Gear Motor,ideal for making robots.
Light weight, high torque and low RPM.
Fine craftsmanship,durable,not easy to wear.
With excellent stall characteristics,can climb hills easily.
You can also easily mount a wheel on the motor’s output shaft.

Specification:

Rated voltage	DC 12V
Speed	300RPM
Shaft diameter	3mm
Diameter	12mm
fuselage without shaft length	26mm
Output axial length	10mm
Output Gear Ratio	1:100
Screw	M3
Quantity	1pcs

model	Parameter
12GAN20	Voltage		Non-loaded		Rated load			stall
	Voltage range (V)	Rated voltage	speed (RPM)	current (A)	speed (RPM)	current (A)	torque (KG.CM)	torque (KG.CM)	current (A)
	6-12	12	300	0.05	240	0.09	0.6	4.00	0.3

Features:
Small volume, torsion big,all metal gear, durable, not easy to wear.
Great replacement for the rusty or damaged DC geared speed reduce motor on the machine.
Widely used on Boat,Car,Electric Bicycle,Fan,Home Appliance.
